NICHICON Expands the UCM Series with the Addition of φ12.5 to φ18 mm Capacitors
Author: Nichicon
5/29/2019
SCHAUMBURG, IL – Nichicon Corporation is expanding its UCM Series product line with the addition of φ12.5 mm to φ18 mm size capacitors. The UCM Series are high-capacity, high-ripple current chip-type aluminum electrolytic capacitors.
Nichicon developed its enhanced UCM Series product line to meet the need for chip-type aluminum electrolytic capacitors in electronic component surface mounting. These new products can serve as automotive-related equipment power supply backups or as small, high-capacity and high-ripple current capacitors for high-density mounting of telecommunications equipment.
These expanded products have approximately 1.9 times higher capacity and 2.1 times higher ripple current than the existing 105 ℃ chip products in the UCD series. This is accomplished by applying high-capacitance electrolytic foil and thin electrolytic paper, as well as optimizing the combination of components and structure used.
The product is guaranteed to 5,000 hours at 105 ℃. The series will be produced at Nichicon (Ohno) Corporation in Fukui Prefecture, Japan, and at Nichicon (Iwate) Corporation in Iwate Prefecture, Japan.
Main Specifications
| Rated voltage range | 25 V to 100 V DC |
| Rated capacitance range | 130 μF to 5,100 μF |
| Category temperature range | -55 °C to +105 °C |
| Product dimensions | φ12.5 mm ×13.5L mm to φ18 mm × 21.5L mm |
| Life | 105 °C 5,000 hours guaranteed [φ12.5×13.5L to φ18×21.5L] |
| Terminal shape | Chip type |
| Samples | Expanded ratings from October 2018 |
| Mass production | Planned 1 million / month from March 2019 |
| Sample prices | From 150 yen |
Comparison of Electrical Characteristics of Same-Sized Products
| Rated voltage (V) | Case size φD × L (mm) | Capacitance (μF) | Rated Ripple current (mArms) (at 105 °C 100kHz) |
||||
| UCD Series (Current product) |
UCM Series (New product) |
Increase | UCD Series (Current product) |
UCM Series (New product) |
Increase | ||
| 35 | 12.5×13.5 | 680 | 910 | ×1.3 | 1,100 | 1,420 | ×1.3 |
| 16×16.5 | 1,000 | 1,800 | ×1.8 | 1,800 | 1,910 | ×1.1 | |
| 63 | 12.5×13.5 | 220 | 360 | ×1.6 | 800 | 1,250 | ×1.6 |
| 16×16.5 | 470 | 620 | ×1.3 | 1,410 | 1,740 | ×1.2 | |
| 100 | 12.5×13.5 | 68 | 130 | ×1.9 | 500 | 1,050 | ×2.1 |
| 16×16.5 | 150 | 240 | ×1.6 | 793 | 1,500 | ×1.9 | |
