PCW0G561MCO1GS

Download Datasheet RoHS Compliant

AEC-Q200 Compliant

Spice Model 3D CAD Drawing Lifetime Calculator

Specifications Have Questions?

Specifications

Capacitance

560 µF

Capacitance Tolerance

-20%~20%

DF Measurement Condition

20℃, 120Hz

ESR @ 20°C/100kHz

15 mΩ

High Frequency Ripple Current

2150 mA

Lead Spacing

3.2 mm

Leakage Current

672 µA

Life/Endurance

2000 h

Low Frequency Ripple Current

107.5 mA

Packaging Type

Embossed Carrier Taping / Mosture Proof Packing

Size

φ8x7L

Status

Under Development

tanδ(DF)

0.08

Temperature Range

-55℃~125℃

Type

Surface Mount

Voltage

4 V
