Home / Products / Aluminum Electrolytic Capacitors / Miniature Aluminum Electrolytic Capacitors / High Reliability Type / UPH / UPH2W121MHD

UPH2W121MHD

Download Datasheet RoHS Compliant

Spice Model 3D CAD Drawing Lifetime Calculator

Specifications Package Options Have Questions?

Specifications

Type

Aluminium

Mounting Type

Radial Lead

Capacitance

120 µF

Capacitance Tolerance

-20%~20%

tanδ(DF)

0.2

Voltage

450 V

Low Frequency Ripple Current

820 mA

ESR @ 20°C/100kHz

0 mΩ

Leakage Current

2260 µA

Life/Endurance

2000 h

Temperature Range

-40℃~105℃

Size

φ16x40L

Lead Spacing

7.5 mm

Lead Spacing Tolerance

0.5 mm

Packaging Type

Bulk(No Terminal Forming) / Bag Packing

Status

Mass Production

Package Options

UPH2W121MHD1SZ

Bending & Cut / Bag Packing

UPH2W121MHD1AA

Bending(Snap-in) / Bag Packing

UPH2W121MHD1CA

Cut / Bag Packing

UPH2W121MHD1CC

Cut / Bag Packing

UPH2W121MHD1CM

Cut / Bag Packing

UPH2W121MHD1CP

Cut / Bag Packing

UPH2W121MHD1CT

Cut / Bag Packing

UPH2W121MHD1CV

Cut / Bag Packing
