UVC2G150MPD

Download Datasheet

Spice Model 3D CAD Drawing Lifetime Calculator

Specifications Package Options Have Questions?

Specifications

Type

Aluminium

Mounting Type

Radial Lead

Capacitance

15 µF

Capacitance Tolerance

-20%~20% %

tanδ(DF)

0.25 tanδ

DF Measurement Condition

20℃, 120Hz

Voltage

400 V

Low Frequency Ripple Current

150 mA

High Frequency Ripple Current

225 mA

Leakage Current

340 µA

Life/Endurance

2000 Lo

Temperature Range

-40℃~105℃ °C

Size

φ10x16L mm

Lead Spacing

Lead Spacing Tolerance

0.5

Packaging Type

Bulk(No Terminal Forming) / Bag Packing

Status

Last Time Buy

Package Options

UVC2G150MPD1CA

Cut / Bag Packing

UVC2G150MPD1CC

Cut / Bag Packing

UVC2G150MPD1CM

Cut / Bag Packing

UVC2G150MPD1CP

Cut / Bag Packing

UVC2G150MPD1CT

Cut / Bag Packing

UVC2G150MPD1CV

Cut / Bag Packing

UVC2G150MPD1TD

Bulk(No Terminal Forming) / Taping(AMMO-Pack)

UVC2G180MPD1AA

Bending(Snap-in) / Bag Packing
