3D Model Library
We provide 3D CAD models so you can design with confidence. Find 3D CAD data for our aluminum electrolytic capacitors and conductive polymer aluminum solid electrolytic capacitors below, available in STEP and IGES formats.
Search for model by case size (i.e. 10x10)
| Document Type | Document Title | Description | Published Date |
|---|---|---|---|
| 3D Model |
4x3.9 Series
|
Chip Type Aluminum Electrolytic Capacitors | 11/22/2017 |
| 3D Model |
4x4.5 Series
|
Chip Type Aluminum Electrolytic Capacitors | 11/22/2017 |
| 3D Model |
4x5 Series
|
Radial Lead Type Conductive Polymer Aluminum Solid Electrolytic Capacitors | 11/22/2017 |
| 3D Model |
4x5.2 Series
|
Chip Type Conductive Polymer Aluminum Solid Electrolytic Capacitors | 11/22/2017 |
| 3D Model |
4x5.4 Series
|
Chip Type Aluminum Electrolytic Capacitors | 11/22/2017 |
| 3D Model |
4x5.5 Series
|
Chip Type Conductive Polymer Aluminum Solid Electrolytic Capacitors | 11/22/2017 |
| 3D Model |
4x5.8 Series
|
Chip Type Aluminum Electrolytic Capacitors | 11/22/2017 |
| 3D Model |
4x7 Series
|
Chip Type Aluminum Electrolytic Capacitors | 11/22/2017 |
| 3D Model |
51x100 Series
|
Screw Terminal Type Aluminum Electrolytic Capacitors | 11/22/2017 |
| 3D Model |
51x105 Series
|
Screw Terminal Type Electric Double Layer Capacitors | 11/22/2017 |
