UBW1C332MHD

Download Datasheet RoHS Compliant

AEC-Q200 Compliant

Spice Model 3D CAD Drawing Lifetime Calculator

Specifications Package Options Have Questions?

Specifications

Capacitance

3300 µF

Capacitance Tolerance

-20%~20%

ESR @ 20°C/100kHz

0 mΩ

Lead Spacing

7.5 mm

Lead Spacing Tolerance

0.5 mm

Leakage Current

1584 µA

Life/Endurance

3000 h

Low Frequency Ripple Current

1815.7 mA

Mounting Type

Radial Lead

Packaging Type

Bulk(No Terminal Forming) / Bag Packing

Size

φ16x30.5L

Status

Mass Production

tanδ(DF)

0.2

Temperature Range

-55℃~135℃

Type

Aluminium

Voltage

16 V

Package Options

UBW1C332MHD1SZ

Bending & Cut / Bag Packing

UBW1C332MHD1AA

Bending(Snap-in) / Bag Packing

UBW1C332MHD1CA

Cut / Bag Packing

UBW1C332MHD1CC

Cut / Bag Packing

UBW1C332MHD1CM

Cut / Bag Packing

UBW1C332MHD1CP

Cut / Bag Packing

UBW1C332MHD1CT

Cut / Bag Packing

UBW1C332MHD1CV

Cut / Bag Packing
